| Electric Parameters | Rated Voltage:220V/380V
| Rated Current :16A/32A
| Frequency:50/60Hz
| Insulation Resistance:> 1000MΩ
| Terminal Temperature Rise:<50K
|
|
| Mechanical Performance | Mechaincal Life:>1000 times no-load plug in/ off
| Withstand Impact:Dropping from a 1 m- height and running- over by a 2T vehicle.
| Coupled Insertion Force:45N-100N |
|
| Material | Enclosure:Thermoplastic, flame retardant grade UL94 V-0
| | Cable Material:TPU
| Terminal:Copper alloy, silver plating
|
|
Plug Type
| |
Environment
| Work Temperature:-30℃ ~ +50℃
| Work Humidity:5%~ 95%
| Work Altitude:<2000m
|
|
